Avenger Shuttle

Avenger Shuttle use the New Aero tube design styles. The frame is designed from the head tube to the down tube, the seat tube, and the rear fork , all are use the Toray high stiffness carbon fiber materials. It's using the internal EPS and wax combined molding progress technology, make the frame quality more stable.

Shuttle -SL It presents ultra-light product characteristics and brings sufficient riding comfort, bringing infinite comfort and enjoyment to cyclists during their road riding journey.

This Bike Avenger Shuttle UCI Approved.

2025 New Carbon Road bike frame Avenger Shuttle（Special Customization）

• Type: Aero Full Carbon Disc road frame Shuttle
• Finish: UD carbon finish

• Material:Toray T800/ T1000

• Weave: UD

• Tire cleanrance: Max up to 700*32C

• Rear axle:142*12mm

• Front axle:100*12mm

• Rotor diameter:140/160mm

• Frame Weight: 950±40g (Normal Version)

• Fork weight: 430±15(Normal Version)

• Headset: FSA NO.55R

• BB: T47-B (External)
• Available sizes: 50/52/54/56/58cm

Avenger Shuttle Carbon Frameset part details :

Frame weight (Normal Version)   with small parts (Hanger/SP clamp..)

50cm:930+-15g

52cm:935+-15g

54cm:947+-15g

56cm:966+-15g

58cm:993+-15g

Frame weight (Super light Version) with small parts (Hanger/SP clamp..)

50cm:776+-15g

52cm:780+-15g

54cm:795+-15g

56cm:814+-15g

58cm:828+-15g

Fork weight:

430+_10g(Normal Version)    380+_10g(Super light Version)

Seatpost (Length 350mm): 90+_10g     w/o Clamp parts(39g)

Handlebar: 330+_10g
